Malahit DSP 2 SDR Overview - I Wasn't Sure I Would EVER See This! -

Video Description

I believed I may never see this, and that is okay, given the current world situation! I am proud to have received my Malahit DSP2 and I am very content with this SDR. In this episode, I give a very brief overview of the SDR and the basic features of it. 18650 Batteries are needed (2) for this SDR. I purchased these, though I doubt they are 5800mAh (We'll test that soon). - https://amzn.to/35WFAn2 The above link is an affiliate link. More Information on the Malahit DSP Software Defined Radio: Team Malahit - https://malahiteam.com/en/ CQDX.RU Malahit Writeup - http://www.cqdx.ru/ham/new-equipment/malahit-malachite-dsp2-sdr-hf-vhf-uhf-radio-receiver/ SWLing.com link - https://swling.com/blog/2019/11/the-new-malahit-dsp-a-portable-all-in-one-wideband-sdr-receiver/ From QRZNOW.com - https://qrznow.com/the-malahit-dsp-portable-sdr-receive/ "Advantages: 3.5 inch capacitive screen 2-layer board structure, higher performance Adopt a sound unit, 2 vibrating chambers, the speaker comes with a sound chamber, the bass sound quality is very full Features: DSP SDR Receiver for Malahit Capacitive touch screen Stlink V2 System Default frequency range: 50KHz-2.0GHz Demodulation mode: AM, LSB, NFM, WFM,(CW, MIN SNR) Product Parameters: The radio is built on the principle of SDR-the function is determined by loaded software; Frequency Range: from 50 KHz to 2.0GHz (Registered version) All types of analog modulation: AM, LSB, NFM, WFM; (CW, MIN SNR) Powerful functions: variable filter width, adaptive noise suppressor, threshold noise suppressor, for Noise Blanker, AGC, equalizer; Fully functional chip msi001; The powerful stm32H 743VIT6 with a clock frequency of 480 MHz is applied; 3.5-inch display touch screen; Controls: 2pcs; encoders with buttons and touch screen; It is powered by an external TYPE-C interface or battery (Built-in battery 3.7V 3800mAh ), which can be charged by TYPE-C. Consumption: 300mA when listening to headphones; The reception on built-in telescope or external antenna is to improve the HF reception on telescope antenna, and an additional board with source follower has been developed. The board will be built into standard receiver design. Connect to computer via USB, which can transfer CAT, IQ and audio. 160 kHz span, with scalability; Sensitivity: Under the condition of up to 250MHz, s/w is 0.3μV = 10dB; 15. Due to the characteristics of msi001 chip used, dynamic blocking range is about 85dB. With backlight control; SMA female antenna socket #hamradio #SDR #SWL
