How Different Types of Suspension System Works? Explained in Details

Video Description

How Different Types of Suspension System Works? Explained in Details Video Credits (Please check out these channels also): [The Wheel Network] Double link front and multi-link rear suspension - https://youtu.be/h7waZ1xAyqk [KYBEurope] How Suspension Works - https://youtu.be/YQ2hqC4_pWI [Monroe Australia & New Zealand] What are shock absorbers? - https://youtu.be/RvSOXX44Ym8 Suspension System: The automobile vehicle's frame and body are mounted on the front and rear axle not directly but through some form of springs and shock absorbers. This is done to damp road shocks transmitted parts that perform this function are called a suspension system. Thus, the suspension system includes springs, shock absorbers, and mountings. The suspension system of a motor vehicle is divided into rear-end suspension and front-end suspension. Types of Suspension Systems: Independent suspension: In this type of suspension, each front wheel is independently supported by a coil, torsion bar, or leaf spring. Most passenger cars now use independent front suspension, in which the coil spring system is the most common. Types of Independent suspension: 1. Macpherson Strut Suspension 2. Double Wishbone Suspension 3. Multilink Suspension 4. Trailing Arm Suspension Non-Independent or Rigid axle suspension: This type of suspension was universally used before independent front wheel suspension was introduced. It may use either two longitudinal leaf springs, as shown in the figure, or transverse springs, usually in conjunction with shock absorbers. These assemblies are mounted similarly to rear leaf spring suspensions. Types of Non-Independent or Rigid axle suspension: 1. Solid Axle Leaf Spring Suspension 2. Solid Axle Coil Spring Other Suspension Types: 1. Air Suspension 2. Hydro Elastic Suspension Disclaimer: This video is just for educational purposes only. We are not in the auto repair business nor publish automotive service manuals. This video is not reviewed or authorized by any vehicle manufacturer. This video is intended only as general guidance. Every system is slightly different, so refer to the owner’s manual of your vehicle for any specific information about your model. Remember that only proper service and repair procedures will ensure your car's safe and reliable operation. Copyright Disclaimer: Copyright Disclaimer under section 107 of the Copyright Act 1976, allowance is made for “fair use” for purposes such as criticism, comment, news reporting, teaching, scholarship, education, and research. Fair use is a use permitted by copyright statute that might otherwise be infringing. Non-profit, educational, or personal use tips the balance favor of fair use. Watch our recent video on Car Transmission: https://youtu.be/ftJKqKuppF4 Video on Car Engine Parts: https://youtu.be/x70VqMrXrbs Download the PDF:- https://www.theengineerspost.com/types-of-suspension-system/ Follow us on Facebook:- https://www.facebook.com/fanpageengineerspost Visit our Website for more articles:- https://www.theengineerspost.com/ Thanks for watching, and subscribe for more.
