This Focusrite 18i20 surprised me with many faults!

Video Description

Thanks PCBWay for sponsoring this video: https://pcbway.com/g/M525r4 #focusrite #repair #electronics #smaart Second channel! https://www.youtube.com/@Tony359_2 Join me on Patreon! https://www.patreon.com/Tony3599 𝐁𝐮𝐲 𝐦𝐞 𝐚 𝐜𝐨𝐟𝐟𝐞𝐞: https://www.buymeacoffee.com/tony359 𝐓𝐰𝐢𝐭𝐭𝐞𝐫/𝐗: https://twitter.com/tony359 Focusrite 2i2 repair video https://www.youtube.com/watch?v=Xygb2XrQjKw ARCAM AVR-280 repair videos Part 1: https://www.youtube.com/watch?v=SrR5L15Rau0 Part 2: https://www.youtube.com/watch?v=C16InSw-Oq4 Gearspace forum thread https://gearspace.com/board/so-much-gear-so-little-time/853311-crosstalk-between-discrete-preamps-inputs.html Kron's cave blog https://khronscave.blogspot.com/2019/04/41-focusrite-scarlett-18i20-1st-gen.html FOCUSRITE OFFICIAL REPLY UPDATE: Reply received on 29th November 2024 -------------------------------------------- I just wanted to thank you for your patience on this. We have taken some time to review the performance you raised here and compare it with our latest generation 18i20. As you are aware we have acknowledged that there was an issue with the first few production units of 18i20 1st Generation, however, this was something we made changes to improve and rolled into the production of newer 1st Gen units. Since then we have continued to improve the performance of our products and with the latest 4th Generation range we have significantly better cross-talk performance than we were able to achieve on the first generation of the product. Some key specs to note are: Maximum Cross Talk Level (Channel 1-2) 1st Gen: -33dBFS @ 20Hz 4th Gen: -73dBFS @ 20kHz This results in an improvement of 40dB - 4th Gens cross-talk is 16 times quieter than the equivalent 1st gen product. Minimum Cross Talk Level (Channel 1-2) 1st Gen: -92dBFS @ 8kHz 4th Gen: -115dBFS @ 20Hz This is a 23dB improvement of the lowest cross talk measurement (4th Gens lowest cross talk point is 4.9 times quieter than the equivalent 1st gen product), and actually an 82dB improvement for the 20Hz measurement point on 4th Gen vs 1st Gen - 294 times quieter! I hope this provides some further context and reassurance. ------------------------------ 00:00 Intro 01:06 Discovering the issues 03:02 The 18i20 is dead!! 08:05 50Hz issue 12:05 recapping and test 17:05 1V troubleshooting 22:28 regulator test and replace 26:52 Focusrite customer service 28:25 Test the repaired 18i20 30:14 The issue is not fixed! 35:38 Focusrite response 36:40 The modification 38:54 Repair fail! 39:40 Thermal analysis 40:59 Outro ===== Local Elevator by Kevin MacLeod is licensed under a Creative Commons Attribution 4.0 licence. https://creativecommons.org/licenses/by/4.0/ Source: http://incompetech.com/music/royalty-free/index.html?isrc=USUAN1300012 Artist: http://incompetech.com/
