How to Hijack Intel Mac : X-GPU Introduction Part 3

Video Description

We can confirm from the schematics(MacBooks) that all Intel Macs with Core i Series(until 2019 model) is using the hardware PCIe bifurcation strap. Some of them were strapped to x16, or x8 x8, or x8 x4 x4 depending on what they had been designed for. The same strap also works for iMac series, so far we have tested it on 2009, 2010, 2011, 2013 iMac. X-Kepler has the same footprint with all GK107 based architecture: Geforce GT650M Geforce GT640M Geforce GT750M Geforce GT755M Quadro K1000M Quadro K1100M Quadro K2000M X-Whistler has the same footprint with several AMD Whistler lineup(small form factor): Radeon HD 6750M Radeon HD 6770M Radeon HD 6490M Radeon R9 M370X (MBP 15" 2015) NevBolt-1 is designed for Thunderbolt 1 on MacBook 13" 2011 & 2012 NevBolt-2 is designed for Thunderbolt 1 on MacBook 15" & 17" 2011 & 2012 Contents in this video: 00:00 - Intel Mac similarities with Windows machines. 01:20 - PCIe Block Diagram explained 05:20 - Bifurcation switch location 05:44 - Conclusion The X-GPU Project couldn’t get this far without the incredible works from these people: OpenCore Team at Dortania MacProUpgrade Group @rossmanngroup UEFITOOL Team : CodeRush@Nikolaj Schlej VGA BIOS modders on MacRumors @dosdude1 Acidanthera Project - vit9696 @pldaniels for flexBV Hackintosh Community Robert Feranec MacBook Logic Board Repair group MacBook Board Repair Community and the list goes on…. Credit for Mac Pro 7,1 picture at 00:41 : https://www.reddit.com/r/macpro/comments/fmgs2j/mac_pro_71_2019_upgrades_5700_xt_highpoint_pcie/
