WLED on ESP32 – Setup Guide (with Audio Reactive)

DroneBot Workshop September 28, 2025
Video Thumbnail
DroneBot Workshop Logo

DroneBot Workshop

@dronebotworkshop

About

Welcome to the Workshop! The DroneBot Workshop is the place where I work with Arduino, Raspberry Pi, ESP32, and lots of other cool microcontrollers, components, and sensors. This is a channel for learning and understanding. While I do build projects, most episodes focus on showing you HOW things work, so you can use the information to bring your own designs to life. Every video has a corresponding article on my website at https://dronebotworkshop.com , along with the diagrams and code samples you’ll need to build your own creations. You can also participate in discussions on my Forum at https://forum.dronebotworkshop.com. Please note that I no longer do any sponsored videos, enquiries for these will be ignored! If you'd like to know more about me or the DroneBot Workshop you can read the FAQ at https://dronebotworkshop.com/about-dronebot-workshop/faq/ And if you have technical questions please ask them on the Forum. Welcome to the Workshop! I hope you enjoy your stay! Bill

Video Description

We’re making LED Strips dance to the music with WLED and an ESP32! Get started right away, no code required! Article: https://dronebotworkshop.com/wled/ More articles and tutorials: https://dronebotworkshop.com Join the conversation on the forum: https://forum.dronebotworkshop.com Subscribe to the newsletter and stay in touch: https://dronebotworkshop.com/subscribe/ WLED is an incredible open-source project that turns an ESP32 into a sophisticated LED strip light controller. Capable of working with virtually any type and size of LED strip, this versatile product can be installed and configured without requiring a single line of code. And even better- you can control it with an app, a web-based interface, or even use it with Home Assistant and Alexa! Today, we will learn everything required for a successful WLED project. We’ll determine the best type of ESP32 for our situation and learn how to select the correct LED strip. Then we will install WLED using its web-based installer and configure it to drive both a NeoPixel LED Strip and an 8x8 addressable LED array. We’ll also add “Audio Reactive” capability to our setup using a small and inexpensive I2S microphone. Perfect for dancing to the music! Here is the Table of Contents of today's colorful episode: 00:00 - Introduction 01:11 - WLED 03:06 - Selecting an ESP32 06:40 - Installing WLED on ESP32 10:23 - Selecting LED Strips 18:34 - Hooking Everything Up 25:32 - WLED Setup & Demos 30:32 - Audio Reactive WLED 34:00 - Audio Reactive WLED Demo 35:33 - Conclusion Whether you want to control a single strip or thousands of addressable LEDs, WLED is up to the task. I’m sure you’ll have fun with this project, and I hope you enjoy the video! Bill
